Our LED holographic film screens offer a lightweight design (2KG/㎡) and thin profile (1-3mm), while providing exceptional transparency (with a visual transmittance rate of up to 99%).They are visually stunning, versatile in appearance, and easy to install.These screens represent the latest trends in LED holographic film technology. With a singlesided power supply reaching up to 1.5 meters, they effortlessly adhere to various glass surfaces within 3 meters, instantly transforming ordinary glass into a dazzling display. Additionally，they support arbitrary cutting and shping,offering
| Model | XTH2.5 | XTH3.5 | XTH3.9 | XTH5 | XTH6 | XTH8 | XTH10 |
| Pixel Pitch(mm) | 2.5 | 3.5 | 3.9 | 5 | 6.25 | 8 | 10 |
| Pixel Density(pixels/㎡) | 160,000 | 81,225 | 65,536 | 40,000 | 25,600 | 15,625 | 10,000 |
| LED Type | SMD1212 | SMD1515 | SMD1717 | SMD2020 | SMD2020 | SMD2020 | SMD2020 |
| Module Size(W*H) | 1000*250mm | 1000*112mm | 1000*125mm | 1000*160mm | 1000*208mm | 1000*256mm | 1000*320mm |
| Module Resolution(W*H) | 400*100 dots | 285*32 dots | 255*32 dots | 200*32 dots | 160*32 dots | 125*32 dots | 100*32 dots |
| Visual Transparency | 90% | ||||||
| Panel Weight(kg) | 2kg | ||||||
| Input Voltage | AC 100-240V | ||||||
| Brightness(cd/㎡) | 800～5000 | ||||||
| Brightness Adjustment | Programmable/Automatic/Manual | ||||||
| Viewing Angle(H/V) | 140°/140° | ||||||
| Gray Scale(bit) | 13/14 | ||||||
| Driving Method | Static | ||||||
| Refresh Rate(Hz) | 3840/7680 | ||||||
| Contrast Ratio | 7000:1 | ||||||
| Color Temperature(K) | 2000-10000 (Adjustable) | ||||||
| Max/Avg. Power Consumption(w/㎡) | 600/200 | ||||||
| Serviceability | Front/Rear | ||||||
| IP Rating | IP30 | ||||||
| Operating Temperature | -40～60℃ | ||||||
| Operating Humidity(RH) | 10%～80% | ||||||
| Working Life(Hours) | 100000 | ||||||
